Brand: BVV

0.9CF ECO Vacuum Oven - 4 Wall Heating, LED display, LED's - 4 Shelves Standard

0.9CF ECO Vacuum Oven - 4 Wall Heating, LED display, LED's - 4 Shelves Standard

SKU: SKU:09ECO

Ordering a large quantity of this item?
As long as the order total is more than $2K you can:

Regular price $1,096.15 USD
Regular price Sale price $1,096.15 USD
Sale Sold out
Shipping calculated at checkout.

Availability: Online | Will Call Locations Stock May Vary

View full details
0.9CF ECO Vacuum Oven - 4 Wall Heating, LED display, LED's - 4 Shelves Standard

Ovens offer:

  • The guaranteed industry standards ability to lose less than 1” Hg over a 24-hour period.
  • The reliable deep vacuum that reaches below 0.1 torr. with stainless steel compression-fit tubing and stainless steel instrumentation valves.
  • Uniform heat is key to an effective oven. Our ovens offer 7% temperature uniformity across all shelves with offering ±1⁰ stability in temperature.
  • Comes standard with the maximum number of shelves and a well-lit LED interior.
  • Items Included: 5' 37⁰ female flared HVAC hose; USA power cord; and oven operation manual. You'll get the complete package only with Best Value Vacs.

Key Oven Features:

  • 1/4" JIC Vacuum Port with included 5' HVAC Hose

  • Easy Vac-Release Dial allows the release of the vacuum without disconnecting the pump or purge

  • Stainless steel interior for a sanitary, easy-to-clean look

  • Overload circuit breaker for electrical protection

  • Comes standard with 4 (0.9CF Eco models) or 5 shelves (1.9CF Eco models)

Specifications:

Electrical 10L Solvent Pro Series Rotary Evaporator Shelves Up to 8 Sliding Shelves at one Time
Reinforced Steel with sides to secure product
Shelf Capacity(Area): 129in^2
Total Shelf Capacity: 1034 in^2 or 7.2ft^2
Dimensions (LxW): 11-3/8" x 11-3/16"
Internal Chamber Material: Polished Stainless Steel
Dimensions (LxWxH): 11.5" x 11.75" x 10.75"
Door 1/2" Tempered Glass Window
Integrated LED's
Window Dimensions (LxH): 11.75" x 11"
Replaceable Gasket Material: Silicone
Temperature Control Four Wall Heating
LED PID Controller
Temperature Range - 212F
Temperature Stability: +/- 1.8F or 1C
Automatic Over Shoot Shut Down
Over Temp Alarm
Weight & Dimensions Outside Dimensions (LxWxH): 24.5" x 22" x 21"
Weight: 115lbs
Vacuum Gauge Ranging From -1inHg to -30inHg Compliance CE Listing Recognized
ISO 9001:2008
ISO 13485" 2003
Manufactured in Acc. w/ Q/TIWY7-2004
IEC68-2-3
Maximum Vacuum Level -29.9inHg / 75.4 cmHg / -1 MPa

Note: This oven does NOT contain a vacuum pump. An external pump is required to achieve vacuum pressure

Note: This item is a freight ship item and will ship Via UPS ground Freight. Expedited freight can only be calculated by calling customer service 331-281-0154. All orders with expedited freight through the website will not be honored and will need to be re-quoted. A valid Phone Number IS REQUIRED to ship, Otherwise UPS freight Cannot Contact you for a delivery setup window. Freight Time is 2-5 Days. West Coast 5 Days, Midwest 2 days, East Cost 3-4 days.
