Performance Capabilities:
Best Value Vacs makes every effort to provide oven performance capabilities in a standardized format. We're not interested in juking our stats to make a sale. Instead, our goal is to provide quality, transparent production capabilities that meet the demands of our professional customers.
- Temperature Stability: ±1.0 °
- Temperature Uniformity: within 4% of the temperature setpoint.
- Heat-Up Time: 20 minutes.
- Ultimate Vacuum: <500 µmHg / mTorr / micron
- Time to Vacuum: 5 minutes to 29"Hg using our VE Series 12cfm Dual Stage Vacuum Pump.
- Vacuum Hold: guaranteed to lose less than 1"Hg (25.4 torr) in 24 hours.
Specifications:
| Electrical | Shelving | ||
| Voltage | 120V | Ships With | 4 Heated Shelves |
| Frequency | 60Hz | Shelf Dimensions (LxW) | 17" x 17.25" |
| Power | 1050W | Shelf Capacity | 293 in2 |
| Current | 16A | Total Shelf Capacity | 1173 in2 / 8.2 ft2 |
| Plug | IEC C13 (unit ships with detachable NEMA 5-15p cable) | Door | |
| Internal Chamber | Seal | Silicone on Tempered Glass | |
| Heating | Individual Direct-Heat shelves | Window Dimensions (LxH) | 15.5" x 16.25" |
| Chamber Material | Stainless Steel | Lights | 4 strips of LEDs provide clear, bright view of interior |
| Dimensions (LxWxH) | 17.7" x 17.7" x 17.7" (450mm x 450mm x 450mm) | Handle | Aluminum |
| Vacuum Gauge | Exterior | ||
| Style | Glycerin-filled for accuracy and longevity | Dimensions (LxWxH) | 30" x 27" x 27" |
| Range (units) | -30 to 0 (inHg) / -1 to 0 (bar) | Weight | 260 lbs |
Capacity and Throughput Planning
Oven capacity requirements vary widely by the producer. We wanted to create a method to assist in determining the best oven match for your operation, based on a few of the parameters of your extraction and of your desired purge. We based this formula on an expected extraction yield of 25%, with an extract-density of 1 g/in2. Using the following variables, this formula is designed to provide an estimate of your required shelving capacity:
- Size = Extraction Batch Size (lbs)
- Number = Runs per 24h Period
- Purge = Your desired purging duration (hours)
- Area Required (ft2) = [(Size) * (Number) * (Purge+1)] / 122
- Area Required (in2) = (Size) * (Number) * (Purge+1) * 1.18
Note: This item is a freight ship item and will ship Via Ground Freight. Freight Time is 2-5 Days. West Coast 5 Days, Midwest 2 days, East Coast 3-4 days.
