Dramm Hydra200 Manual Wind Sprayer, 115V Electric
A hand-crank reel and a large tank keep this Hydra200 setup simple to run. The 200 gallon sumped tank drains completely after each job. Power comes from a 1.5 HP electric motor on 115 V, which keeps exhaust out of closed growing spaces. Dramm rates the Hydra electric drive at 4 gpm. The triplex piston pump runs up to 550 psi with a fully adjustable regulator. Fine sprays, coarse sprays and longer throws all come from the same machine. A hybrid agitation system uses bypass flow and dedicated nozzles to keep the mix in suspension. The hose winds by hand onto a convex reel that stops bird nesting. A lock and variable tension drag keep the hose from freewheeling off the reel. The powder coated steel frame rolls on pneumatic tires with an easy steering design. Corrosion resistant fittings, stainless or plated, replace brass in the plumbing. An optional 20 gallon second tank can be added later.
Handling a 200 Gallon Pull Type Sprayer
Park the rig on level ground and lower the swivel jack before filling. Fill the tank three quarters with water, start the pump, then add chemicals premixed in a bucket. Finish filling with water once agitation is running. Unlock the reel and set enough drag to stop the hose from spilling. Walk the hose out, spray, then crank it back while guiding it evenly across the reel. Lock the reel before moving the unit. Clean the agitation nozzles if flow looks weak. Keep the regulator at its rated setting and never touch the screw under its cap. Check pump oil and add SAE 10W-30 as needed. Flush everything with clean water after each job, and never fill with reverse osmosis water.
Key Features
- 200 Gallon Sumped Tank: Large capacity that drains completely.
- Manual Locking Reel: Variable tension drag stops freewheeling.
- 1.5 HP Electric Motor: 115 V drive, 4 gpm.
- 550 PSI Triplex Pump: Adjustable regulator for pattern and reach.
- Hybrid Agitation: Recirculation plus nozzles keep powders suspended.
- Corrosion Resistant Fittings: Stainless or plated parts in place of brass.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Dramm |
| Series | Hydra200 |
| Tank | 200 gallons, sumped; optional 20 gallon second tank |
| Motor | 1.5 HP electric, 115 V |
| Pump Output | 4 gpm |
| Pump | Triplex piston, stainless, direct drive |
| Maximum Pressure | 550 psi, adjustable regulator |
| Agitation | Hybrid bypass recirculation with agitation nozzles |
| Hose Reel | Manual wind convex reel with lock and variable tension drag |
| Hose Length | 150, 200, 250 or 300 ft |
| Fittings | Corrosion resistant (stainless or plated) package |
| Frame | Powder coated steel, pneumatic tires, swivel jack |
| Dimensions | 90 x 60 x 60 in (L x W x H) |
| Warranty | 6 months Dramm limited |
