EZ-Clone 750 Mag Drive Replacement Water Pump, 700 GPH | For 30, 60 and 120 Cloners

EZ-Clone 750 Mag Drive, the EZ Cloner Pump for Original Systems

Cuttings in an aeroponic cloner live on the spray from the manifold, so the pump sets the pace for every stem in the lid. This unit is the EZ-Clone 750 Mag Drive, the factory pump in the original 30 site cloner. It pushes 700 GPH through the manifold and its 360 degree misters. EZ-Clone's own testing found it can also replace the pumps in the 60 and 120 site systems. The motor runs on 120 V, 60 Hz and draws 0.9 A. Inside there is one moving part, a magnetically driven impeller with a plastic coating. The design is oil-free and has no motor seals, so nothing can leak oil into the reservoir or wear through a seal. It runs cool, which helps keep the water in the misting chamber at a steady temperature. An adjustable filter on the intake holds back debris before it reaches the misters. It shares the same submersible, bottom-draw layout as the other EZ-Clone pumps. EZ-Clone backs it with a lifetime limited warranty against manufacturing defects.

Fitting a Replacement Water Pump in the Cloner

Unplug the cloner and lift the lid, with the cuttings still in their collars, onto a clean tray. Drain the reservoir and wipe out any slime or root debris from the floor. Pull the old pump off the manifold riser and set the new one in the same spot. Push the riser onto the outlet until it seats firmly, then check that the manifold sits level. Close the intake filter slightly if loose debris keeps clogging the misters. Refill with fresh water and plug the pump in before the lid goes back on. Watch each mister for a full, even spray pattern. A weak or uneven pattern usually points to a blocked sprayer, not the pump. Rinse the intake filter at every reservoir change, because root hairs collect there fast. Run the pump around the clock or on a cycle timer, whichever your rooting schedule calls for. Keep a spare on the shelf. A failed pump during week one can cost a full tray of cuttings.

Key Features

• Factory Pump for the 30 Site: The same 750 Mag Drive that ships in the original EZ-Clone 30.
• 700 GPH Flow: Drives the manifold and 360 degree misters at full spray.
• Oil-Free Mag Drive: One moving part and no motor seals to leak or wear out.
• Runs Cool: Adds little heat to the water in the misting chamber.
• Adjustable Intake Filter: Holds back debris before it reaches and clogs the misters.
• Lifetime Limited Warranty: EZ-Clone covers it against manufacturing defects.

Technical Specifications
