Iluminar Wieland 240V Power Cord NEMA 6-15 | DE & CMH Fixtures | 15 ft

Iluminar Wieland 240V Power Cord for DE and CMH Fixtures

The Iluminar Wieland cord pairs a NEMA 6-15P plug with a German Wieland female mate at the fixture end. Length runs 15 ft / 4.5 m, long enough to reach a wall-mounted 240V outlet without forcing the ballast against the canopy. The Wieland RST series mate is rated IP67, so the connection holds in humid flower rooms. NEMA 6-15 is by definition a 240V plug, despite legacy retailer copy that lists 120V. The 250V-rated 15 A connector is the giveaway. The 120V version uses NEMA 5-15 and the 277V version uses NEMA L7-15, so plug shape alone tells you the voltage at a glance.

240V Power Cord for DE CMH Fixtures with Wieland RST Female to Male NEMA 6-15

Growers typically place this on a dedicated 240V circuit with a 15 A breaker. NEMA 6-15 will not fit a 120V wall outlet, so confirm the panel can deliver 240V before ordering. The Wieland female end mates with any standard Wieland-equipped DE or CMH ballast, not just iluminar. That makes it useful for mixed-brand rooms running Gavita, Sun System, or Phantom-class ballasts. Pair the cord with a 16 AWG-or-better whip when extending past 15 ft. Long lamp runs can sit at the ignitor's distance limit. The German Wieland connector family is standard across most pro horticultural fixtures.

Key Features

• Wieland Female Connector: German RST series mate with IP67 rating for humid flower rooms
• NEMA 6-15P Wall Plug: Standard 240V 15 A plug fits any properly wired NEMA 6-15 receptacle
• 15 ft / 4.5 m Length: Reaches typical wall outlets without pulling the ballast toward the canopy
• Cross-Brand Compatibility: Works with any DE or CMH ballast using a Wieland RST input
• IP67 Sealed Mate: Holds against condensation in late-flower rooms running 70%+ RH
