iluminar IL Series 1-10V Daisy Chain Dimmer Cord | iL5 iL8 iL12 | 1.8m

iluminar IL Series Daisy Chain Dimmer Cord for iL5, iL8, iL12

The IL Series dimmer cord runs 1.8 m / ~5.9 ft between IL fixtures. It carries the 1-10V dim signal across iL5, iL8, and iL12 LEDs with no AC load. Each IL fixture has two RJ14 dim ports, so a single cord plugs into one upstream port and one downstream. That delivers pure pass-through with no splitter required. The RJ14 modular jack matches most horticultural 0-10V drivers, which keeps spare-cord sourcing simple. This is a fixture-to-fixture jumper for the dim signal only, not the AC line. AC input still runs through the dedicated AC daisy chain cord.

iluminar 1-10V Daisy Chain Dimmer Cord for IL Series LED Grow Light Accessories

Growers typically place the dim cord along the same path as the AC daisy chain to keep the wiring loom tight. Fixture-to-fixture interconnect distance stays under 6 ft on this length. 0-10V control runs are stable to roughly 50 m of total cumulative length, which leaves headroom in most rooms. Mix-brand pairings can drop into the same RJ14 dim cord. Driver dim curves between brands are not always identical, so spot-check brightness on the first install before scaling. A dropped dim cable will not power-cycle the fixture. Both dim ports are electrically identical, so plug into either jack on the IL fixture.

Key Features

• 1-10V / 0-10V Dim Signal: Carries the analog dim signal between IL Series fixtures with no AC load
• RJ14 Modular Connector: Same jack used across most 0-10V horticultural drivers, easy to source spares
• 1.8 m / 5.9 ft Length: Matches standard 4x4 to 5x5 bench-to-bench fixture spacing
• Two Ports per Fixture: Pass-through chaining requires no splitter or terminator block
• IL Series Compatibility: Direct-fit for iluminar iL5, iL8, and iL12 LED grow lights

Technical Specifications
