Netafim 5mm Tee Connector, Thread x Barb x Thread
In a drip system built on micro tubing, every connection point is a place where water can leak or a line can pull loose. This Netafim tee handles that connection with a barb on one side and threads on the other two. The barbed leg pushes into a hole punched in the poly distribution line. The two threaded legs screw into the inside of 5 mm feed tubing rather than relying on friction alone. Netafim lists this barb tee style for micro tubes with a 3.0 mm inside diameter. Threading the tube onto the fitting gives a firm grip that resists blow-off when the system pressurizes. Because the tee splits into two outlets, one punch in the distribution line feeds two separate tubes. That halves the number of holes along the line, which leaves fewer potential leak points. It also keeps a pair of feed lines heading to one pot or two neighboring plants from a single spot. The fittings are black, which blends in on benches and media. Each pack holds 250 tees, enough to plumb a sizable greenhouse section in one go.
Installing Netafim Connectors on a Distribution Line
Start by cutting two lengths of feed tubing to reach from the line to the plants. Twist one end of each tube onto a threaded leg until it seats fully against the body of the tee. Choose the spot on the distribution line where both feed lines should leave. Punch a clean hole there with a hole punch sized for this barb. Press the barbed leg straight into the hole so the barb locks behind the pipe wall. Run the free ends of the tubes to the pots and attach Netafim drip stakes or spray stakes. Netafim describes this tee as the link between a poly distribution line and UV Super Flex polyethylene feed line. Keep the tube lengths on each tee similar so both outlets see the same pressure loss. Flush the distribution line before inserting tees, so debris does not travel into the micro tubing. Check every joint during the first run and reseat any tube that weeps. If a plant moves, the threaded tube unscrews from the tee without damaging it. Spare tees in the pack make repairs quick when a line gets cut.
Key Features
- Barb x Thread x Thread: One barb into the distribution line, two threaded outlets.
- Two Feed Lines per Hole: Splits one punch into two 5 mm tubes.
- Threaded Grip: Tubing screws onto the legs for a secure hold under pressure.
- 5 mm Micro Tubing: Matched to 5 mm feed line with a 3.0 mm ID.
- Stake Ready: Feeds Netafim drip stakes and spray stakes.
- Black Body: Low visibility on benches and growing media.
- 250 Pack: Bulk quantity for greenhouse and nursery installations.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Netafim |
| SKU | 32500-001335 |
| Fitting Type | Tee, thread x barb x thread |
| Inlet | Barb, inserts into punched poly distribution line |
| Outlets | 2 threaded, for 5 mm micro tubing |
| Compatible Tubing | 5 mm feed tubing, 3.0 mm ID |
| Color | Black |
| Pack Quantity | 250 |
