Netafim Disc Filter 3/4 in MPT x MPT 140 Mesh 17 GPM Maximum Flow
Advanced Filtration for Optimal Irrigation:
The Netafim 3/4" Disc Filter is a state-of-the-art solution designed to significantly enhance the filtration efficiency of your irrigation system. Crafted for durability and long-lasting performance, this disc filter facilitates an efficient backflush process, ensuring better irrigation uniformity and protection against contaminants.
Innovative Disc Filter Technology:
- Groove Design for Superior Trapping: The disc rings in the filter feature crisscrossing grooves that form a network, effectively trapping debris both between and on the outside of the discs. This design ensures that only clean water passes through to your irrigation system.
- Pressure-Induced Filtration: As water enters the filter and pressure builds, it compresses the disc rings tightly together. The water is then forced through the grooves of the disc rings, leaving trapped debris behind and allowing only clean water to flow through.
- Optimal Flow Range: This 3/4 inch filter operates efficiently with a flow range of 1 - 12 GPM, making it versatile for various irrigation requirements.
3-D Technology for Enhanced Protection:
- Depth Filtration: The disc filtration method is depth filtration, which is highly effective for surface water and water containing organic contaminants.
- High Filtration Efficiency: Thanks to the unique design of the disc's grooves and a sturdy backbone structure, Netafim's disc filters boast the industry's highest filtration efficiency. They are
- Capable of stopping three times more dirt particles than competing products.
- Compact and High-Performance: The Netafim Disc Filter is the perfect solution for growers who require high-performance irrigation filtration without a large footprint.
Product Specifications:
- Flow Range: 1 - 12 GPM, catering to a wide range of irrigation scenarios.
- Maximum Pressure: 140 PSI, suitable for various system pressures.
- Filtering Surface Area: 25 square inches, providing extensive filtration coverage.
- Filtering Volume: 5.8 cubic inches, ensuring ample space for trapped debris.
- Dimensions: Length of 5 22/32 inches and Width of 7 15/32 inches.
- Weight: 0.66 lbs, lightweight and easy to handle.
- Distance Between Ends: 6 inches, for easy integration into existing systems.
- Inlet/Outlet Diameter: 3/4 Inch Male, compatible with standard irrigation components.
The Netafim 3/4" Disc Filter is an essential addition to any irrigation system, offering unmatched efficiency in debris removal and water purity, ensuring the health and growth of your crops.
