FlexNet Netafim Manifold Pipe, 2 in With 30 in Outlets
Close row spacing needs a manifold with an outlet ready at every bed. This FlexNet coil, item 43003-005242 and model 05FX02PIPE50-30, places one every 30 in. Each outlet is an integral welded connector with a 1/2 in female thread, set into the pipe at that fixed spacing. A tee or elbow start connector threads in, and the dripline lateral fits onto that connector. Netafim fittings seal in these outlets without Teflon tape or glue. The pipe is a 2 in nominal size, with a 2.0 in inside diameter and a 0.030 in wall. Its maximum recommended working pressure is 36.2 psi. It is made from fully recyclable polypropylene that resists UV and chemicals, with a black identification stripe. When empty it lies flat, can be stepped on or driven over, and shows zero axial elongation under pressure. A 328 ft coil with welded outlets weighs about 33 lb.
Laying Out 2 Inch FlexNet Pipe at 30 Inch Rows
Maximum manifold lengths for this pipe assume 5/8 in thinwall dripline at 92% emission uniformity on level ground. At this outlet spacing and 1 psi friction loss, the manifold runs 98 ft with laterals drawing 1.46 GPM each. The same layout shortens to 70 ft when each lateral draws 2.50 GPM. Allowing 2 psi of friction loss stretches those figures to 128 ft and 90 ft. Match the outlet to each bed before charging the line, then thread in the start connectors by hand. Twist-lock tee and elbow start connectors fit 630 and 875 thinwall dripline, including Space-It and DripNet PC. Unused outlets close with a half-inch MPT short plug. A coupler kit joins coils, and a line end cap in the matching size closes the far end. The pipe works on the surface or buried, with no special installation tools. After harvest, drain the manifold and roll it back up with the outlets in place.
Key Features
- Outlets every 30 in: Integral welded connectors with 1/2 in female threads.
- 2 in nominal size: 2.0 in inside diameter, 0.030 in wall.
- Rated to 36.2 psi: Maximum recommended working pressure.
- Polypropylene: 100% recyclable, UV and chemical resistant.
- 328 ft coil: About 33 lb with welded outlets.
Technical Specifications
| Specification | Value |
|---|---|
| Item Number | 43003-005242 |
| Model | 05FX02PIPE50-30 |
| Nominal Size | 2 in |
| Outlet Spacing | 30 in |
| Outlets | Integral welded, 1/2 in female threaded |
| Inside Diameter | 2.0 in |
| Outside Diameter | 2.09 in |
| Wall Thickness | 0.030 in |
| Max Recommended Working Pressure | 36.2 psi |
| Material | 100% recyclable polypropylene |
| Coil Length | 328 ft (100 m) |
| Coil Weight | 33 lb |
| Identification | Black stripe |
| Warranty | 3 years |
