Compact 205W Pro LED for Tight Grow Tents and 2.6 x 2.6 ft Coverage
The PhotonTek SQ200W is a 205W square-bar LED delivering 508 µmol/s PPF at 2.5 µmol/J across 2.6 x 2.6 ft. The fixture blends white, deep red, and far red diodes calibrated for high-intensity uniform output. A clear-glue layer over the bars holds 99% transmittance with full IP65 protection. Onboard 0-10V dimming runs in 1% increments.
Compact LED for Tight Spaces and Home Grow Tents Up to 2.6 x 2.6 ft
Growers typically hang the SQ200W 12 to 18 inches above canopy and dim from 50% to 100% across the flowering ramp. Mount the fixture in a 2x2 or 3x3 tent for primary coverage or as a supplemental tier in vertical racks. Pair the unit with the P-TEK Digital Lighting Controller or any 0-10V controller for scheduled sunrise and sunset cycles.
Key Features
- 205W at 2.5 µmol/J: Pulls 508 µmol/s PPF across 2.6 x 2.6 ft with a square-bar design tuned for compact tents.
- White + Deep Red + Far Red: Spectrum blend of top-bin white, red, and far-red diodes delivers high-intensity uniform output.
- IP65 Clear-Glue Coating: Thin protective layer holds 99% light transmittance while resisting humidity and irrigation spray.
- 1% Dimming via P-TEK: Fully dimmable in 1% increments via the included 0-10V dimmer or P-TEK controller.
- Passive Convection Cooling: Advanced heatsink eliminates the fan for silent operation and longer driver lifespan.
Technical Specifications
| Specification | Value |
|---|---|
| Watts | 205W |
| PPF | 508 µmol/s |
| Efficacy | 2.5 µmol/J |
| Coverage | 2.6 x 2.6 ft |
| Diodes | White + Deep Red + Far Red |
| Dimming | 0-10V (1% increments) |
| IP Rating | IP65 |
| Cooling | Passive natural convection |
| Controller | P-TEK Digital Lighting Controller (up to 100 fixtures) |
| Warranty | 3 years |
