Enhance your home's water pressure with the Red Lion Pressure Boosting Pump 3/4 HP - 1" MNPT Discharge. Ideal for residences with a municipal water source and incoming water pressure less than 45 psi, this advanced pressure boosting system ensures steady and reliable water pressure throughout your home, even when multiple fixtures are in use.
Applications:
Perfect for homes with municipal water pressure below 45 psi, this system maintains steady pressure across multiple water fixtures.
Features & Benefits:
- Ready to Install: Factory-assembled package with no need for on-site wiring. Includes a 6-foot, 115-volt power cord for easy installation.
- Consistent Pressure: Boosts water pressure to provide a steady output, ensuring your home has the water pressure it needs.
- Space-Saving Design: Built-in control unit eliminates the need for a separate pressure switch and pressure tank, saving space and reducing costs compared to traditional booster systems.
- Run-Dry Protection: Prevents damage to the pump if the water source is turned off.
- Auto-Run Feature: Automatically flushes the system if idle for more than 24 hours, preventing debris build-up and damage to the impeller.
Specifications:
- Model: RBSS-75FC
- Item Number: 97080708
- UPC: 0 10121 00056 8
- HP: 3/4
- Volts: 115
- Amps: 9
- Intake: 1" FNPT
- Discharge: 1" MNPT
Pressure Boosting Info:
- Incoming Water Pressure from Main Water Supply:10 PSI: 55 PSI Outgoing at 2 GPM
- 20 PSI: 65 PSI Outgoing at 2 GPM
- 30 PSI: 75 PSI Outgoing at 2 GPM
- 40 PSI: 75 PSI Outgoing at 2 GPM
- 50 PSI: 75 PSI Outgoing at 2 GPM
Pressure Boost at "X" PSI:
- 1 GPM: 46 PSI
- 2 GPM: 45 PSI
- 5 GPM: 42 PSI
- 10 GPM: 35 PSI
- 15 GPM: 25 PSI
- 20 GPM: 12 PSI
The Red Lion Pressure Boosting Pump is a reliable and efficient solution for improving water pressure in homes with low municipal supply. Its compact design, ease of installation, and advanced features make it a valuable addition to any household needing consistent water pressure.
